Copper Wire 0.5hp Self Priming Jet Pump / Brass Impeller Pump With Electric Motor
Features of Pump
1. Brass impeller
2. C & U bearing
3. Main Parts are Produced By Ourself.
4. Patent design
5. Have Ability To Design The Products Based On Your Original Samples.
6. 12 months warranty
7. CE TUV RoHS ISO9001 ISO14001 certification
Electric motor water pumps are able to offer high flow rates, be used in flow irrigation system in gardening, agriculture fittings. With single phase, able to offer high flow rates, provide smooth, regulate the flow rate over a wide range without damaging the pump.
|HP / KW||1~220V||(l/min)||(m)||(M)||(mm)||(Kg)|
|JET-60B||0.5 / 0.37||1.6||2850||42||40||9||1"x1"||460x210x220||13.5|
|JET-80B||0.75 / 0.55||3.6||2850||46||45||9||1"x1"||460x210x220||14|
|JET-100B||1 / 0.75||4.8||2850||52||50||9||1"x1"||460x210x220||16.2|
Other voltages and frequencies available on request
|Transmission medium||Clean Water|| |
|Pump body||Cast Iron|| |
|Impeller||Brass/Noryl PPO|| |
|Motor housing||Aluminum|| |
|Stator&Rotor||1.Cold -rolled silicon steel sheet by high speed punching machine. 2. 100% high quality copper wire|
|Front cover||Cast Iron||Brass plate embedded to avoid impeller jam|
|Bearing||Chinese Best Quality Bearing||NSK,SKF or on request|
|Mechanical seal||Graphene/Ceramic||Silicon Carbon|
|Shaft||Carbon Steel||Stainless Steel|
|Insulation||Class B||Class F|
|Voltage||220-240V Single Phase||On Request|
|Automatic Pressure Control System||No||Yes|
|Cooling Type||External Ventilation|| |
|Max. Suction lift||9M|| |
|Max. Fluid Temperature||+60℃|| |
|Max. Environment Temperature||+40℃|| |
|Connect Type||Thread|| |
|CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC|
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide the free easy-damaged spare part for problems caused by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-made operation. After expiration, our company provides cost spare parts for maintenance.
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and samples making, also we can advise how to make the products according to customers' target prices.
1. Q: What’s the MOQ?
A: Trial sample order is ok.
2. Q: Are you factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept to use our logo?
A: Yes, we can do OEM for you.
4. Q: How can I get the pump?
A: Usually we suggest express for samples, if the volume reaches 1m³, the Seaway will be better.
5. Q: What’s the warranty period?
A: 1 year.
