Wilo Type Household Electric Self Suction Pump 1.5hp 100% Output Power
Place of Origin | China |
---|---|
Brand Name | ZOZHI |
Certification | CE/SGS/ISO |
Model Number | JET-150L |
Minimum Order Quantity | 1pc |
Price | negotiated |
Packaging Details | Packed in cartons , overall size:530x240x260mm/pc, N.W.: 24.5kgs |
Delivery Time | 25 working days after received your payment |
Payment Terms | T/T, L/C |
Supply Ability | 30000pcs/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Name | Self Priming Pump | Application | Pumping |
---|---|---|---|
Output | 1.5HP / 1KW | Flow Max | 80L/Min |
Head Max | 60M | Suction Max | 9M |
Inlet/Outlet | 1"x1" | Speed | 2850RPM |
Highlight | self priming centrifugal water pump,self priming water pump |
Wilo Type Household Electric Self Suction Pump 1.5hp 100% Output Power
Self Priming Pump SELF PRIMING JET PUMP FEATURE
1) Good suction and ideal household electric pump both at head and capacity
2) Double sealed precision ball bearing
3) Capacitor start & run type
Self Priming Pump APPLICATIONS
Zhongzhi JET-L series self-priming pumps are highly efficient jet pumps with excellent suction even with air bubbles. The pump consists of a single impeller, centrifugal pump, and jet pipe with a nozzle. These series pumps are particularly suitable for water supply in domestic installations, small-scale agriculture watering, and a self-priming operation is demanded.
STRUCTURAL CHARACTERISTICS
Main Specification | Standard | Optional |
Transmission medium | Clean Water | |
Pump body | Cast Iron | |
Impeller | Brass | Noryl PPO |
Motor housing | Aluminum | |
Stator&Rotor | 1. Cold-rolled silicon steel sheet by high-speed punching machine. 2. 100% high-quality copper wire | |
Front cover | Cast Iron | |
Bearing | Chinese Best Quality Bearing | NSK, SKF, or on request |
Mechanical seal | Graphene/Ceramic | Silicon Carbon |
Shaft | Carbon Steel | Stainless Steel |
Insulation | Class B | Class F |
Protection | IP44 | IP54 |
Voltage | 220-240V Single Phase | On Request |
Frequency | 50HZ | 60HZ |
Thermal protection | No | Yes |
Automatic Pressure Control System | No | Yes |
Cooling Type | External Ventilation | |
Max. Suction lift | 9M | |
Max. Fluid Temperature | +60℃ | |
Max. Environment Temperature | +40℃ | |
Installation | Horizontal | |
Connect Type | Thread | |
CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC |
TECHNICAL DATA
Model | Output | A | R.P.M. | Q.Max | H.Max | S.Head | Pipe Dia | LxWxH | N.W. | |
HP / KW | 1~220V | (l/min) | (m) | (M) | (mm) | (Kg) | ||||
JET-60L | 0.5 / 0.37 | 3 | 2850 | 42 | 40 | 9 | 1"x1" | 410x185x220 | 12 | |
JET-80L | 0.75 / 0.55 | 3.6 | 2850 | 46 | 45 | 9 | 1"x1" | 480x210x220 | 16 | |
JET-100L | 1 / 0.75 | 4.8 | 2850 | 52 | 50 | 9 | 1"x1" | 480x210x220 | 17 | |
JET-150L | 1.5 / 1.1 | 6 | 2850 | 80 | 60 | 9 | 1¼ "x1" | 530x240x260 | 24.5 | |
JET-200L | 2 / 1.5 | 8.2 | 2850 | 100 | 65 | 9 | 1¼ "x1" | 530x240x260 | 26 |
Other voltages and frequencies available on request
ADVANTAGE
100% a high-quality copper,100% output
Cold-rolled silicon steel sheet by a high-speed punching machine
Good quality bearing, the surface more smooth, the dimension more precise
Thermal protector
One year warranty
GUARANTEE
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except for the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
