3Hp dual stage electric motor driven Horizontal Centrifugal Pump 130L / Min Flow Max

3Hp dual stage electric motor driven Horizontal Centrifugal Pump 130L / Min Flow Max
3Hp dual stage electric motor driven Horizontal Centrifugal Pump 130L / Min Flow Max 3Hp dual stage electric motor driven Horizontal Centrifugal Pump 130L / Min Flow Max 3Hp dual stage electric motor driven Horizontal Centrifugal Pump 130L / Min Flow Max

Large Image :  3Hp dual stage electric motor driven Horizontal Centrifugal Pump 130L / Min Flow Max

Product Details:

Place of Origin: China
Brand Name: ZOZHI
Certification: CE/SGS/ISO
Model Number: SCM2-45-1

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: negotiated
Packaging Details: Packed in cartons or pallets
Delivery Time: 25 working days after received your payment
Payment Terms: T/T, L/C
Supply Ability: 30000pcs/month
Detailed Product Description
Output: 2HP / 1.5KW Flow Max: 130L/Min
Head Max: 55M Suction Max: 9M
Phase: Single Phase/3phase Voltage: 220-240v
Type: Water Pump Fuel: Electric
High Light:

electronic water pump

,

commercial electric water pump

4. 2.1.
3Hp dual stage electric motor driven Horizontal Centrifugal Pump 130L / Min Flow-Max

Description:

SCM2 series dual-stage centrifugal pump are twin impellers centrifugal pump designed for use in pressurization units for domestic, civil and industrial use. Suitable for sprinkling irrigation and other water supply applications, such as well-pumping, water supplying, decanting, etc.

Technical data:


ModelOutputAR.P.M.Q.MaxH.MaxS.HeadPipe DiaLxWxHN.W.
HP / KW1~220V(l/min)(m)(M)(mm)(Kg)
SCM2-451 / 0.755.22850904091"x1"380x210x24018.8

Other voltages and frequencies available on request

Advantages:

1. The copper we used is 100% copper.
2. Good quality bearing, the surface more smooth, the dimension more precise
3. It can work a long time and it works smoothly
4. It has thermal protector.


Material:

Pump body: Cast Iron
Impeller: Brass
Mechanical Seal: Carbon/Ceramic/Stainless Steel



Operating Limitations:

Max ambient temperature up to 40℃
Max fluid temperature up to 80℃
Max pressure up to 10 bar


3Hp dual stage electric motor driven Horizontal Centrifugal Pump 130L / Min Flow Max 0





3Hp dual stage electric motor driven Horizontal Centrifugal Pump 130L / Min Flow Max 1


Structural Characteristic:


Main SpecificationStandardOptional
Transmission mediumClean Water
Pump bodyCast Iron
ImpellerBrassNoryl PPO
Motor housingAluminum
Stator&Rotor1.Cold -rolled silicon steel sheet by a high-speed punching machine. 2. 100% high-quality copper wire
Front coverCast Iron
BearingChinese Best Quality BearingNSK, SKF or on request
Mechanical sealGraphene/CeramicSilicon Carbon
ShaftCarbon SteelStainless Steel
InsulationClass BClass F
ProtectionIP44IP54
Voltage220-240V Single PhaseOn Request
Frequency50HZ60HZ
Thermal protectionNoYes
Automatic Pressure Control SystemNoYes
Cooling TypeExternal Ventilation
Max. Suction lift9M
Max. Fluid Temperature+60℃
Max. Environment Temperature+40℃
InstallationHorizontal
Connect TypeThread
CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC



Guarantee:

Guarantee for one year from shipped on board date. During the guarantee period, our company will provide the free easy-damaged spare part for problems caused by our quality of production or raw material,  except the damageable spare parts caused by customer's incorrect man-made operation. After expiration, our company provides cost spare parts for maintenance.



Our Service

1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and samples making, also we can advise how to make the products according to customers' target prices.


FAQ

1. Q: What’s the MOQ?
    A: Trial sample order is ok.

2. Q: Are you factory or trading company?
    A: We are a manufacturer.

3. Q: Can you accept to use our logo?
    A: Yes, we can do OEM for you.

4.  Q: How can I get the pump?
    A: Usually we suggest express for samples, if the volume reaches 1m³, the Seaway will be better.

5. Q: What’s the warranty period?
    A: 1 year.
