0.5 Hp Electric Motor Water Pump Garden Watering Electric Water Transfer Pump
Application:
The CPM-130 pump is high-efficient, power-saving and compact in structure, convenient to operate and maintain. The hydraulic characteristic is with high head and small capacity. Pumps should be installed in a covered area, protected against the weather.
Technical Data:
| Model | Output | A | R.P.M. | Q.Max | H.Max | S.Head | Pipe Dia | LxWxH | N.W. |
| HP / KW | 1~220V | (l/min) | (m) | (M) | (mm) | (Kg) |
| CPM-130 | 0.5 / 0.37 | 1.6 | 2850 | 75 | 20 | 9 | 1"x1" | 310x170x230 | 8.9 |
Advantages:
1). 100% high-quality copper,100% output
2). Cold -rolled silicon steel sheet by a high-speed punching machine
3). Good quality bearing, the surface more smooth, the dimension more precise
4). Thermal protector
5). One year warranty
Material and working limits
- Pump body: Cast iron
- Impeller: Brass
- Motor Housing: Aluminum
- Motor Wire: Copper
- Mechanical seal: S.S.&Ceramic & Graphite
- Shaft: 45#steel
- Bearing: China&Ceramic
- Insulation class: B
- Protection class: IP 44
- Rated Voltage: 220V/380V
- Frequency: 50Hz
Structural Characteristics:
| Main Specification | Standard | Optional |
| Transmission medium | Clean Water | |
| Pump body | Cast Iron | |
| Impeller | Brass | Noryl PPO |
| Motor housing | Aluminum | |
| Applications | Garden Watering Pump |
| Stator&Rotor | 1. Cold -rolled silicon steel sheet by a high-speed punching machine. 2. 100% high-quality copper wire |
| Front cover | Cast Iron | |
| Bearing | Chinese Best Quality Bearing | NSK, SKF or on request |
| Mechanical seal | Graphene/Ceramic | Silicon Carbon |
| Shaft | Carbon Steel | Stainless Steel |
| Insulation | Class B | Class F |
| Protection | IP44 | IP54 |
| Voltage | 220-240V Single Phase | On Request |
| Frequency | 50HZ | 60HZ |
| Thermal protection | No | Yes |
| Automatic Pressure Control System | No | Yes |
| Cooling Type | External Ventilation | |
| Max. Suction Lift | 9M | |
| Max. Fluid Temperature | +60℃ | |
| Max. Environment Temperature | +40℃ | |
| Installation | Horizontal | |
| Connect Type | Thread | |
| CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC |
Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide the free easy-damaged spare part for problems caused by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-made operation. After expiration, our company provides cost spare parts for maintenance.
FAQ:
1. Q: What’s the MOQ?
A: Trial sample order is ok.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept to use our logo?
A: Yes, we can do OEM for you.
4. Q: How can I get the pump?
A: Usually we suggest express for samples, if the volume reaches 1m³, the Seaway will be better.
5. Q: What’s the warranty period?
A: 1 year.
