Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller

Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller
Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller

Large Image :  Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller

Product Details:
Place of Origin: China
Brand Name: ZOZHI
Certification: CE/SGS/ISO
Model Number: JSP-355A
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiated
Packaging Details: Packed in cartons , overall size:410x185x220mm/pc, N.W.: 12kgs
Delivery Time: 25 working days after received your payment
Payment Terms: T/T, L/C
Supply Ability: 30000pcs per month
Detailed Product Description
Name: Electric Motor Water Pump Application: Watering
Power: 1HP / 0.75KW Flow Max: 52L/Min
Head Max: 50M Impeller: Brass Impeller
Inlet/Outlet: 1"x1" Frequency: 50 HZ
High Light:

electronic water pump

,

commercial electric water pump


Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller
Descriptions:
These pumps are suitable for handling clean water that does not contain abrasive particles and fluids that are not chemically aggressive to the pump components.


Technical data:


ModelOutputAR.P.M.Q.MaxH.MaxS.HeadPipe DiaLxWxHN.W.
HP / KW1~220V(l/min)(m)(M)(mm)(Kg)
JSP-355A1 / 0.754.82850525091"x1"460x210x22017


Other voltages and frequencies available on request



Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller 0
Jsp series electric motor water pump is high-efficient,power-saving, and compact in structure. It's convenient to operate and maintain with a high head and small capacity. They are suitable for domestic and industrial gardens, hotels, villas and agricultural irrigation, and so on...Pumps should be installed in a covered area, protected against the weather.


Electric Motor Water Pump Features:

1. Brass impeller to guarantee long time use
2. The special spray-paint technique, beautiful and more stable
3. S/S screw
4. Patent design
5. Fine Appearance, High Lift, Low Noise, Low Vibration
6. CE TUV RoHS ISO9001 ISO14001 certification
7. High-efficiency motor

Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller 1

Structural Characteristics:

Main SpecificationStandardOptional
Transmission mediumClean Water
Pump bodyCast Iron
ImpellerBrass/Noryl PPO
Motor housingAluminum
Stator&Rotor1. Cold-rolled silicon steel sheet by a high-speed punching machine. 2. 100% high-quality copper wire
Front coverCast IronBrass plate embedded to avoid impeller jam
BearingChinese Best Quality BearingNSK, SKF, or on request
Mechanical sealGraphene/CeramicSilicon Carbon
ShaftCarbon SteelStainless Steel
InsulationClass BClass F
ProtectionIP44IP54
Voltage220-240V Single PhaseOn Request
Frequency50HZ60HZ
thermal protectionNoYes
Automatic Pressure Control SystemNoYes
Cooling TypeExternal Ventilation
Max. Suction lift9M
Max. Fluid Temperature+60℃
Max. Environment Temperature+40℃
InstallationHorizontal
Connect TypeThread
CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC






Electric Motor Water Pump guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.

 FAQ
1. Q: What’s the MOQ?
A: Trial sample order is ok.

2. Q: Are you a factory or trading company?
A: We are a manufacturer.

3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.

4. Q: How can I get the pump?
A: Usually, we suggest express for samples. If the volume reaches 1m³, the Seaway will be better.

5. Q: What’s the warranty period?
A: 1 year.
