Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller

Place of Origin China
Brand Name ZOZHI
Certification CE/SGS/ISO
Model Number JSP-355A
Minimum Order Quantity 1pc
Price negotiated
Packaging Details Packed in cartons , overall size:410x185x220mm/pc, N.W.: 12kgs
Delivery Time 25 working days after received your payment
Payment Terms T/T, L/C
Supply Ability 30000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Name Electric Motor Water Pump Application Watering
Power 1HP / 0.75KW Flow Max 52L/Min
Head Max 50M Impeller Brass Impeller
Inlet/Outlet 1"x1" Frequency 50 HZ
High Light

electronic water pump


commercial electric water pump


1HP electric motor pump for agriculture

Leave a Message
Product Description

Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller
These pumps are suitable for handling clean water that does not contain abrasive particles and fluids that are not chemically aggressive to the pump components.
Technical data:

Model Output A R.P.M. Q.Max H.Max S.Head Pipe Dia LxWxH N.W.
HP / KW 1~220V (l/min) (m) (M) (mm) (Kg)
JSP-355A 1 / 0.75 4.8 2850 52 50 9 1"x1" 460x210x220 17

Other voltages and frequencies available on request
Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller 0
Jsp series electric motor water pump is high-efficient,power-saving, and compact in structure. It's convenient to operate and maintain with a high head and small capacity. They are suitable for domestic and industrial gardens, hotels, villas and agricultural irrigation, and so on...Pumps should be installed in a covered area, protected against the weather.
Electric Motor Water Pump Features:
1. Brass impeller to guarantee long time use
2. The special spray-paint technique, beautiful and more stable
3. S/S screw
4. Patent design
5. Fine Appearance, High Lift, Low Noise, Low Vibration
6. CE TUV RoHS ISO9001 ISO14001 certification
7. High-efficiency motor
Jsp Series Garden Booster Water Pumps With Pure Copper High-Efficiency Impeller 1
Structural Characteristics:

Main Specification Standard Optional
Transmission medium Clean Water
Pump body Cast Iron
Impeller Brass/Noryl PPO
Motor housing Aluminum
Stator&Rotor 1. Cold-rolled silicon steel sheet by a high-speed punching machine. 2. 100% high-quality copper wire
Front cover Cast Iron Brass plate embedded to avoid impeller jam
Bearing Chinese Best Quality Bearing NSK, SKF, or on request
Mechanical seal Graphene/Ceramic Silicon Carbon
Shaft Carbon Steel Stainless Steel
Insulation Class B Class F
Protection IP44 IP54
Voltage 220-240V Single Phase On Request
Frequency 50HZ 60HZ
thermal protection No Yes
Automatic Pressure Control System No Yes
Cooling Type External Ventilation
Max. Suction lift 9M
Max. Fluid Temperature +60℃
Max. Environment Temperature +40℃
Installation Horizontal
Connect Type Thread

Electric Motor Water Pump guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
1. Q: What’s the MOQ?
A: Trial sample order is ok.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: How can I get the pump?
A: Usually, we suggest express for samples. If the volume reaches 1m³, the Seaway will be better.
5. Q: What’s the warranty period?
A: 1 year.
