Brass Impeller Scm Electric Motor Water Pump , Single Stage Centrifugal Pump Long life

China Brass Impeller Scm Electric Motor Water Pump , Single Stage Centrifugal Pump Long life supplier
Brass Impeller Scm Electric Motor Water Pump , Single Stage Centrifugal Pump Long life supplier Brass Impeller Scm Electric Motor Water Pump , Single Stage Centrifugal Pump Long life supplier

Large Image :  Brass Impeller Scm Electric Motor Water Pump , Single Stage Centrifugal Pump Long life

Product Details:

Place of Origin: China
Brand Name: ZOZHI
Certification: CE/SGS/ISO
Model Number: SCM-22

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: negotiated
Packaging Details: Packed in cartons or pallets
Delivery Time: 25 working days after received your payment
Payment Terms: T/T, L/C
Supply Ability: 30000pcs/month
Contact Now
Detailed Product Description
Power: 1HP /0.75KW Flow Max: 110L/Min
Head Max: 30M Structure: Single-stage Pump
Pipe Size: 1"x1" Feature: Long Life
Products Name: Domestic Pump Usage: Water


Brass Impeller SCM Electric Motor Water Pump, Single Stage Centrifugal Pump Long life




PUMP INSTALLATION AND APPLICATIONS

It can be used to transfer clean water or other liquids similar to water in physical and chemical properties. It is suitable for industrial use and urban water supply, pressure boosting for high buildings and firefighting, garden irrigation, long-distance water transfer, heating ventilation and air controlling, circulation and pressure boosting for cold and hot water, and supporting equipment etc.



FEATURE
1) Enamel technique: clean, healthy, environmental, prevent secondary pollution
2) 100% high quality copper,100% output
3) Cold -rolled silicon steel sheet by a high-speed punching machine
4) Good quality bearing, the surface more smooth, the dimension more precise
5) Thermal protector



STRUCTURAL CHARACTERISTICS


Main SpecificationStandardOptional
Transmission mediumClean Water
Pump bodyCast Iron
ImpellerBrassNoryl PPO
Motor housingAluminum
Stator&Rotor1.Cold -rolled silicon steel sheet by a high-speed punching machine. 2. 100% high-quality copper wire
Front coverCast Iron
BearingChinese Best Quality BearingNSK, SKF or on request
Mechanical sealGraphene/CeramicSilicon Carbon
ShaftCarbon SteelStainless Steel
InsulationClass BClass F
ProtectionIP44IP54
Voltage220-240V Single PhaseOn Request
Frequency50HZ60HZ
Thermal protectionNoYes
Automatic Pressure Control SystemNoYes
Cooling TypeExternal Ventilation
Max. Suction lift 9M
Max. Fluid Temperature+60℃
Max. Environment Temperature+40℃
InstallationHorizontal
Connect TypeThread
CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC



TECHNICAL DATA


ModelOutputAR.P.M.Q.MaxH.MaxS.HeadPipe DiaLxWxHN.W.
HP / KW1~220V(l/min)(m)(M)(mm)(Kg)
SCM-220.5 / 0.3732850752091"x1"310x165x2258.8
SCM-420.75 / 0.553.62850952591"x1"340x210x25012
SCM-501 / 0.754.828501103091"x1"340x210x25013.6




 Brass Impeller Scm Electric Motor Water Pump , Single Stage Centrifugal Pump Long life


OUR SERVICE

1). We are very glad that customer gives us some suggestion for price and products.

2). Any questions, please let us know it in the first by E-mail or Telephone. We can deal with them for you in time.

3). Offer our customers the lowest prices. Streamline the buying and paying processes.

4). Deliver goods to our customers all over the world with speed and precision.

5). Ensure the excellent quality of our products.

6).12 months FREE warranty.

7). Accept OEM


FAQ

1). Q: How about the MOQ?
     A: Usually, it is 50 PCS for each model.

2) .Q: Are you a factory or a trading company?
      A: we make water pump, motor, alternator, and diesel generator since 2006.

3).  Q: Can you accept to use our logo?
       A: Yes, we can. Any OEM are welcome!

4).  Q: What are your payment terms?
      A: 30% deposit by T/T in advance, pay 70% balance against B/L copy.

5).  Q: How about the delivery time?
       A: Usually, 10-30days. But it depends on your order quantity.

6).  Q: How about the warranty?
     A: 1 year from shipped on board date.
