Stainless Steel Automatic Electric Motor Water Pump , Self Priming Jet Pump

Stainless Steel Automatic Electric Motor Water Pump , Self Priming Jet Pump
Stainless Steel Automatic Electric Motor Water Pump , Self Priming Jet Pump

Large Image :  Stainless Steel Automatic Electric Motor Water Pump , Self Priming Jet Pump

Product Details:

Place of Origin: China
Brand Name: ZOZHI
Certification: CE/SGS/ISO
Model Number: CPM-158

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: negotiated
Packaging Details: Packed in cartons or pallets
Delivery Time: 25 working days after received your payment
Payment Terms: T/T, L/C
Supply Ability: 30000pcs/month
Detailed Product Description
Output: 1HP / 0.75KW Flow Max: 110L/Min
Head Max: 32M Suction Max: 9M
Inlet/Outlet: 1"x1" Speed: 2850RPM
Application: Irrigation Material: Cast Iron, Stainless Steel 304
High Light:

electronic water pump


commercial electric water pump

Stainless Steel Automatic Electric Motor Water Pump, Self Priming Jet Pump
Applied to pump such liquid which is clean, no solid matter or frictional matter, low viscous, noncorrosive, non-crystallizable, chemically neutral and close to water.
Such as:
1. Tank filling
2. Domestic water supply
3. Water transfer
4. Pressure boosting
5. Irrigation
CPM centrifugal pump
has a single centrifugal impeller, the impeller is mounted on the end of the motor shaft which directly faces with minimum hydraulic loos, the blades inside the impeller channel transfer energy to the fluid both in the form of pressure and an increase in speed.
After leaving the impeller the fluid passes to the volute and tapered diffuser which transform part of the kinetic energy into pressure energy.

Main SpecificationStandardOptional
Transmission mediumClean Water
Pump bodyCast Iron
ImpellerBrassNoryl PPO
Motor housingAluminum
Stator&Rotor1.Cold -rolled silicon steel sheet by a high-speed punching machine. 2. 100% high-quality copper wire
Front coverCast Iron
BearingChinese Best Quality BearingNSK, SKF or on request
Mechanical sealGraphene/CeramicSilicon Carbon
ShaftCarbon SteelStainless Steel
InsulationClass BClass F
Voltage220-240V Single PhaseOn Request
Thermal protectionNoYes
Automatic Pressure Control SystemNoYes
Cooling TypeExternal Ventilation
Max. Suction lift 9M
Max. Fluid Temperature+60℃
Max. Environment Temperature+40℃
Connect TypeThread


ModelOutputAR.P.M.Q.MaxH.MaxS.HeadPipe DiaLxWxHN.W.
HP / KW1~220V(l/min)(m)(M)(mm)(Kg)
CPM-1300.5 / 0.371.62850752091"x1"310x170x2308.9
CPM-1460.75 / 0.553.628501002591"x1"340x210x25012.2
CPM-1581 / 0.754.828501103291"x1"340x210x25013.8
CPM-1801.5 / 1.16.228501304291"x1"425x250x32021
CPM-2002.0 / 1.59.428501505091"x1"425x250x32023

 Stainless Steel Automatic Electric Motor Water Pump , Self Priming Jet Pump 0
100% high-quality copper,100% output
Cold -rolled silicon steel sheet by a high-speed punching machine
Good quality bearing, the surface more smooth, the dimension more precise
Thermal protector
One year warranty
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide the free easy-damaged spare part for problems caused by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-made operation. After expiration, our company provides cost spare parts for maintenance.
