ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp

  • ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp
  • ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp
  • ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp
  • ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp
  • ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp
Place of Origin China
Brand Name ZOZHI
Certification CE
Model Number YC90S-2
Minimum Order Quantity 1 piece
Price USD piece
Packaging Details Plywood box
Delivery Time 30 work days
Payment Terms L/C, T/T
Supply Ability 1000 piece per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Power 1.1KW Application Industry Machine
Voltage 220V-240V Warranty One Year
Material Cast Iron/Stainless Steel Product Name Electric Motor Water Pump
Color Customer Specifications Motor Single Phase
Feature High Efficiency Duty Cycle Continuous
Frequency 50HZ 60 Hz Oem Availiable
Highlight

ICO 141 Single Phase Ac Motor

,

F Insulation Single Phase Ac Motor

,

1.1kw Electric Engine Water Pump
Leave a Message
Product Description



Electric Single Phase Ac Motor Continuous Duty Cycle YC90S-2 220v 50hz 1.1kw 1.5hp



Electric Motor Water Pump

Product Description





Type/Model : YC90S-2
Output Power : 1.1KW (1.5HP)
Voltage Range : 220 V / 50Hz( customizable)
Housing Type : Cast Iron
Torque : 3.68N.M
Protection Level : IP54 (IP44 and IP55 for optional)
Efficient: 70 %
Speed : 2850rpm
Numbers of Poles 2 pole
Insulation Class : F ( class H customizable)
Cooling Method : ICO 141
Install method : B3 (B5,B35 for optional)

Product Description

YC series heavy-duty single-phase motors are suitable for powering small machine tools and water pumps, especially for family workshops where only a single-phase current supply is available. Motors of the said series are integrated with up-to-date design, made with the best quality materials, and possess a pleasant-looking appearance, outstanding performance, easy maintenance, and reliable running. Moreover, the designations, signs, and nominal values all conform to I.E.C. standards.



YC SERIES SINGLE-PHASE ELECTRIC MOTOR SPECIFICATION TABLE

 YC TECHNICAL DATA
Type Power (kw) Current  (A) @220V Speed (r/min)
3000rpm, 2-pole,50hz
YC80A-2 0.37 3.5 2880
YC80B-2 0.55 5.1 2880
YC80C-2 0.75 6.4 2880
YC90S-2 1.1 8.7 2880
YC90L-2 1.5 11.6 2900
YC100-2 2.2 16.4 2900
1500rpm, 4-pole,50hz
YC80A-4 0.25 3.3 1450
YC80B-4 0.37 4.3 1450
YC80C-4 0.55 5.7 1450
YC90S-4 0.75 7.4 1450
YC90L-4 1.1 10 1450
YC100L-4 1.5 12.9 1450
YC112M-4 2.2 18.5 1450
YC132SA-4 3.0 24.1 1450
YC132SB-4 3.7 28.7 1450




ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 0

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 1

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 2

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 3

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 4

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 5

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 6

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 7

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 8

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 9

ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 10



Electric Motor Water Pump Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.



ICO 141 Single Phase Ac Motor Continuous Duty Cycle YC90S-2 1.1kw 1.5hp 11



F.A.Q.
Q1 Are you a manufacturer or a trading company?
We are a manufacturer of water pumps and motors in China.
Q2 Where is your factory?
Fuan city, Fujian province.
Q3 What are your terms of payment?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance , balance before shippment.
Q4 What about the delivery time?
Normally, 30 days after the receipt of payment.
Q5 About shipment?
By sea, By air, and By express delivery.
Q6 About sample?
Available.
