House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft

China House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft supplier
House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft supplier House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft supplier

Large Image :  House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft

Product Details:

Place of Origin: Fuan, Fujian
Brand Name: ZOZHI
Certification: CE
Model Number: QB-70

Payment & Shipping Terms:

Minimum Order Quantity: 1CBM
Price: negotiated
Packaging Details: Box+Pallet
Delivery Time: 30 working days after received your payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30000 pcs per month
Contact Now
Detailed Product Description
Structure:: Single-stage Pump Product Name:: Peripheral Water Pump
Front Cover:: Cast Iron/Aluminum With Brass Insert Mechanical Seal:: Carbon/Ceramic/Stainless Steel
Shaft:: Carbon Steel Protection:: IP 44
Power:: Electric Pump Body:: Cast Iron/Stainless Steel/Brass
Impeller:: Single Impeller Motor Housing:: Alloy Aluminium
Insulation:: Class B/Class F

House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft



Description:

This unit has a robust steel pump and motor body to last you for years of service. This compact unit is suitable for indoor/weather-protected use for general household supply, water transfer, and pressure boosting (not suited for dirty water such as ponds, lakes, and rivers, etc. Able to pump 45 liters per minute this pump is designed for pumping clean tank water.
Some 1000 watt power-draining monsters not only pump up plenty of water but they also pump up your electricity bill!!!!
At just 550 watts power drain this pump is much, much cheaper to run and will still pump plenty of tank water for your garden irrigation needs.



Advantages:

1. High-quality Capacitor: Adopt a good capacitor made by advanced production line, heat resistant to 85 ℃, the working lift is more than 10000 hours.

2. Cold rolled stator: Good quality cold-rolled silicon from the Wugang brand made by a high-speed punching machine, less burr, high concentricity, and stability.



3. Coil with 100% copper wire: 100% copper wire, with thermal protector, make the pump stop working automatically at the condition of jam or
overload, etc.

4. No leakage of winding: 100% coil testing to make sure each coil energized, and no leakage at high voltage condition





House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft



TECHNICAL DATA (220~240V/50HZ)



Model Single-phase Motor n=2850r/min
Input max Output Power Current Q.max H.max Suct.max
kW kW HP A L/min m m
QB-60 0.55 0.37 0.5 2.5 35 35 9
QB-70 0.8 0.55 0.75 3.8 45 50
QB-80 1.1 0.75 1.0 5.2 50 55
QB-90 1.5 1.1 1.5 7 90 60

House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft

House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft

House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft

Our Customer

House Electric Motor Water Pump Qb-70 45l/ Min 50m Hmax Pressurized Carbon Steel Shaft

Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide the free easy-damaged spare part for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect man-made operation. After expiration, our company provides cost spare parts for maintenance.



Our Service:
1. Free maintenance within 12 months guarantee.
2. We cooperate with customers to design and develop a new product.
3. We'd like to assist you in arranging delivery things, test things or others on your request.
4. Customize production.
1. We are a professional manufacturer with more than 13 years experience in Electric motor
2. We are Made in China Gold Supplier
3.we test the material before production and three to four times when producing to ensure the goods in good quality, also we produce according to request
4.we can be your OEM manufacturer with your authorization of brand.



FAQ:
Q: What’s the MOQ?
A: We accept one piece.

Q: Are you a factory or trading company?
A: We are a manufacturer.

Q: Can you accept to use our logo?
A: Yes, we can do OEM for you.

Q: What’s the warranty period?
A: 1 year.

Q: What are the terms of payment?
A: T/T. 30% deposit and 70% against the BL copy or 100% LC at sight.
