IEC Standard Hollow Shaft Motor Three Phase HS112M1-4 4KW 5.5HP Washdown Application

  • IEC Standard Hollow Shaft Motor Three Phase HS112M1-4 4KW 5.5HP Washdown Application
Place of Origin China
Brand Name ZOZHI
Certification ISO
Model Number HS112M1-4
Minimum Order Quantity 10PCS
Price negotiated
Packaging Details Packed in cartons,veneer case or wooden case.
Delivery Time 25 working days after received your payment
Payment Terms T/T, L/C
Supply Ability 10000pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Output 4kw Pole 4
Rotation Direction Clockwise Motor Bearing C&U (SKF For Choice)
Efficiency IE1,IE2,IE3 Motor Housing Aluminum
Protection Class IP54/IP55 Insulation Class F Class
Product Name Hollow Shaft Motor
High Light

hollow shaft electric motor

,

hollow shaft hydraulic motor
Leave a Message
Product Description

IEC Standard Hollow Shaft Electric Motor Three-Phase HS112M1-4 4KW 5.5HP for washdown applications

Hollow Shaft Motor

Hollow Shaft Electric Motor Description



The hollow shaft induction motor has the characteristics of low-temperature rise, good heat dissipation, low noise, high efficiency and energy saving, beautiful appearance, small size, and maintenance imitation. In addition, a seamless connection with professionally added pumps for worry-free operation is one of the ideal powers for high-pressure cleaning equipment.



High-pressure cleaning is recognized as one of the most scientific, economical, and environmentally friendly cleaning methods. The hollow shaft electric motor with a high-pressure pump cleans the dirt with a high-pressure water column. It can peel off the ground and wash it away to clean the surface of the object.



Advantage:

High-quality magnetic material, good heat dissipation

high efficiency, low temperature, low noise

Seamlessly connect with equipment for worry-free operation.



characteristics

A.C.:three-phase

Type: HS112M1-4

Housing: aluminum

Voltage:400V

Power:4kw

Heating technology: electric

Rotational speed :Max:3000rpm；Min:1000rpm

Other characteristics: 4-pole, for pumps, for agribusiness, for washdown applications, for offshore application,hollow-shaft



Main Specification Standard Optional
Motor housing Aluminum
Stator&Rotor 1. Cold-rolled silicon steel sheet by high-speed punching machine. 2.100% high-quality copper wire
bearing C & U
Shaft C#45
Insulation Class F
Protection IP55
Voltage 220/380V Three Phase
Frequency 60HZ
thermal protection Yes
Installation B3 Hollow shaft 24mm





Hollow Shaft Electric Motor Application

Hollow shaft motor connection high-pressure pump use for self-service car washes and professional high-pressure washers that require a longer service life



hollow shaft electric motor



Production line

IEC Standard Hollow Shaft Motor Three Phase HS112M1-4 4KW 5.5HP Washdown Application 1



Production data

Three-Phase 4 Poles 1500Rpm 50Hz
FRAME POWER RPM COSφ EFF.% VOLT AMPERE
KW H.P. P.F.   V A
711-4 0.25 0.35 1370 0.73 64 400 0.8
712-4 0.37 0.5 1350 0.74 68 400 1.1
713-4 0.55 0.75 1350 0.75 66 400 1.6
90L1-4 1.5 2 1400 0.82 78 400 3.4
90L2-4 2.2 3 1400 0.79 77 400 5.4
90L3-4 2.6 3.5 1400 0.80 78 400 7.4
100L1-4 2.2 3 1400 0.80 81 400 5.1
100L2-4 3 4 1410 0.80 81 400 6.9
100L3-4 4 5.5 1420 0.80 82 400 9.4
100M1-4 4.4 6 1420 0.82 83 400 10
112M1-4 4 5.5 1420 0.80 83 400 9
112M2-4 5.5 7.5 1430 0.82 84 400 12.1
112M3-4 6.2 8.5 1425 0.82 84 400 13.5
112L-4 7 9.5 1430 0.80 85 400 13.8
132S1-4 5.5 7.5 1430 0.82 84 400 11.7
132S2-4 7.5 10 1430 0.84 84 400 15.4
132M1-4 9.2 12.5 1430 0.90 85 400 17.8
132M2-4 11 15 1430 0.90 87 400 21.3
132M3-4 12.5 17 1430 0.88 84 400 26
160M1-4 15 20 1450 0.86 89 400 29
160M2-4 18.5 25 1450 0.86 90 400 34



IEC Standard Hollow Shaft Motor Three Phase HS112M1-4 4KW 5.5HP Washdown Application 2



HOLLOW SHAFT MOTOR SWIMMING POOL PUMP ELECTRIC MOTOR
PRESSURE SWITH PRESSURE SWITCH IEC Standard Hollow Shaft Motor Three Phase HS112M1-4 4KW 5.5HP Washdown Application 8
water pump water pump mechnical seal

IEC Standard Hollow Shaft Motor Three Phase HS112M1-4 4KW 5.5HP Washdown Application 12

Hollow Shaft Motor

Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.



Our service:

1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available. Feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and sample making. Also, we can advise how to make the products according to customers' target prices.



FAQ:

1. Q: What's the MOQ?
    A: We accept one piece.
2. Q: Are you a factory or trading company?
    A: We are a manufacturer.
3. Q: Can you accept using our logo?
    A: Yes, we can do OEM for you.
4. Q: What's the warranty period?
    A: 1 year.
5. Q: What are the terms of payment?
    A: T/T. 30% deposit and 70% against the B.L. copy or 100% L.C. at sight.
