Horizontal Multistage Centrifugal Pump / electric water pump with 100% Copper Wire
Contact me for free samples and coupons.
Wechat: 0086 18588475571
If you have any concern, we provide 24-hour online help.x
|Product Name||Multistage Centrifugal Pump||Application||Fresh Water|
|Output||2.5HP / 1.85KW||Flow Max||170 L/Min|
|Head Max||62M||Input Power||2.4KW|
industrial water pumps,
stainless steel centrifugal pump
Horizontal Multistage Stainless Steel Centrifugal Water Pump 100% Copper Wire
Multistage Centrifugal Pump
*This electric pump adopts stainless steel housing, strong engineering plastic impeller, and middle part, which is corrosion resistant and long-lived.
*This electric pump adopts a low noisy international motor. The pump is equipped with high-quality mechanical sealing, which owns a stable property.
*Beautiful appearance and energy-efficient.
*Small volume, high head, and widely used.
PUMP INSTALLATION AND APPLICATIONS
* Water supply: water filtering and distribution, water to the water district, in charge of pressurized, high-rise
* Industrial boosting: process water system, cleaning system, high-pressure washing system, fire system.
* Industrial liquid conveying: cooling and air conditioning systems, boiler feed and condensate systems,
machine matching, acid, and alkali.
* Water treatment: Ultrafiltration systems, reverse osmosis systems, distillation systems, separators, swimming pool.
*Clean and thin non-flammable and non-explosive medium which doesn't include sold particle or fiber.
*Spring water, soft water, pure water, a light oil, or other chemical media.
*The main material pump is stainless steel and engineering plastic, which can be used in pumping light-mordant medium.
PERFORMANCE DATA AT n=2850 min-1
|Pump Model||Input||Output||Q m3/h||0||1.2||2.4||3.6||4.8||6||7.2||8.4||9.6||10.2|
|MH170 2M||1||0.75||1||H (m)||25||24||23||20||17||13||10||6||2||0|
Q=Flow Rate H=Total dynamic Head In Meters Curve tolerance according to ISO 2548
100% high-quality copper,100% output
Cold-rolled silicon steel sheet by high-speed punching machine
Good quality bearing, the surface more smooth, the dimension more precise
One year warranty
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and samples making, also we can advise how to make the products according to customers' target prices.
1. Q: What’s the MOQ?
A: Trial sample order is ok.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: How can I get the pump?
A: Usually we suggest express for samples, if the volume reaches 1m³, the Seaway will be better.
5. Q: What’s the warranty period?
A: 1 year.
