Double - Stage Hydraulic Water Pump With Iron Cost Pump Body , Class B Insulation

Double - Stage Hydraulic Water Pump With Iron Cost Pump Body , Class B Insulation
Double - Stage Hydraulic Water Pump With Iron Cost Pump Body , Class B Insulation Double - Stage Hydraulic Water Pump With Iron Cost Pump Body , Class B Insulation Double - Stage Hydraulic Water Pump With Iron Cost Pump Body , Class B Insulation

Large Image :  Double - Stage Hydraulic Water Pump With Iron Cost Pump Body , Class B Insulation

Product Details:
Place of Origin: China
Brand Name: ZOZHI
Certification: CE/SGS/ISO
Model Number: SCM2-45
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiated
Packaging Details: Packed in cartons , overall size:380x210x240mm/pc, N.W.: 18.8kgs
Delivery Time: 25 working days after received your payment
Payment Terms: T/T, L/C
Supply Ability: 30000pcs/month
Detailed Product Description
Product Name: Multistage Centrifugal Pump Application: Pumping
Output: 1HP / 0.75KW Flow Max: 90 L/Min
Head Max: 40M Suction Max: 9M
Inlet/Outlet: 1"x1" Speed: 2850RPM
High Light:

high pressure centrifugal pump

,

stainless steel centrifugal pump

Multistage Centrifugal Pump

Multistage Centrifugal Pump SCM2-45 double-stage centrifugal water pump with iron cost pump body for irrigation using 1HP 0.75KW


Multistage Centrifugal Pump Application:

The SCM2 series double-stage centrifugal pumps are with two back-to-back impellers centrifugal pumps, are developed for higher head valve than single impeller pumps, and have extremely high outputs. They are suitable for pumping clean water and chemically non-aggressive liquid, reliable, economical, and simple to use. Pumps should be installed in a covered area, protected against the weather.

Technical Data:

ModelOutputAR.P.M.Q.MaxH.MaxS.HeadPipe DiaLxWxHN.W.
HP / KW1~220V(l/min)(m)(M)(mm)(Kg)
SCM2-451 / 0.755.22850904091"x1"380x210x24018.8

Other voltages and frequencies available on request


Advantages:

1. It is of good quality and at the perfect price.
2  It has a one-year-long warranty.
3. It is economical and energy-saving.
4. It is easy to operate and it is a slight vibration while working.

Structural Characteristics:


Main SpecificationStandardOptional
Transmission mediumClean Water
Pump bodyCast Iron
ImpellerBrassNoryl PPO
Motor housingAluminum
Stator&Rotor1. Cold-rolled silicon steel sheet by a high-speed punching machine. 2. 100% high-quality copper wire
Front coverCast Iron
BearingChinese Best Quality BearingNSK, SKF, or on request
Mechanical sealGraphene/CeramicSilicon Carbon
ShaftCarbon SteelStainless Steel
InsulationClass BClass F
ProtectionIP44IP54
Voltage220-240V Single PhaseOn Request
Frequency50HZ60HZ
Thermal protectionNoYes
Automatic Pressure Control SystemNoYes
Cooling TypeExternal Ventilation
Max. Suction Lift 9M
Max. Fluid Temperature+60℃
Max. Environment Temperature+40℃
InstallationHorizontal
Connect TypeThread
CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC





Double - Stage Hydraulic Water Pump With Iron Cost Pump Body , Class B Insulation 0


Multistage Centrifugal Pump Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.


Our Service:

1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and samples making, also we can advise how to make the products according to customers' target prices.


FAQ:

1. Q: What’s the MOQ?
    A: Trial sample order is ok.

2. Q: Are you a  factory or trading company?
    A: We are a manufacturer.

3. Q: Can you accept using our logo?
    A: Yes, we can do OEM for you.

4.  Q: How can I get the pump?
    A: Usually we suggest express for samples, if the volume reaches 1m³, the Seaway will be better.

5. Q: What’s the warranty period?
    A: 1 year.
