Vortex Agriculture Water Pump 1.5hp / 1.1kw Single Phase With Casting Motor Housing

Vortex Agriculture Water Pump 1.5hp / 1.1kw Single Phase With Casting Motor Housing
Vortex Agriculture Water Pump 1.5hp / 1.1kw Single Phase With Casting Motor Housing

Large Image :  Vortex Agriculture Water Pump 1.5hp / 1.1kw Single Phase With Casting Motor Housing

Product Details:
Place of Origin: China
Brand Name: ZOZHI
Certification: CE/SGS/ISO
Model Number: IDB-60
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiated
Packaging Details: Packed in cartons , overall size:425x200x225mm/pc, N.W.: 21.2kgs
Delivery Time: 25 working days after received your payment
Payment Terms: T/T, L/C
Supply Ability: 30000pcs per month
Detailed Product Description
Product Name: Peripheral Water Pump Application: Pumping
Output: 1.5HP / 1.1KW Flow Max: 60L/Min
Head Max: 70M Suction Max: 9M
Inlet/Outlet: 1"x1" Speed: 2850RPM
High Light:

domestic water pump

,

vortex water pump


Vortex Agriculture Water Pump 1.5hp / 1.1kw Single Phase With Casting Motor Housing


Peripheral Water Pump APPLICATIONS

Zhongzhi vortex water pump is extremely reliable, light, economical, and simple to use, finding many uses in domestic applications, particularly the automatic distribution of water from surge tanks, watering gardens, and for boosting insufficient mains water pressure.

Zhongzhi Peripheral pumps with peripheral impellers can offer high pressure with comparatively low powers and have particularly steady operating curves. And suitable for handling clean water not containing abrasive particles and fluids which are not chemically aggressive to the pump components.




STRUCTURAL CHARACTERISTICS

Main Specification Standard Optional
Transmission medium Clean Water
Pump body Cast Iron
Impeller Brass
Motor housing Aluminum
Stator&Rotor 1. Cold-rolled silicon steel sheet by high-speed punching machine. 2. 100% high-quality copper wire
Front cover Cast Iron Brass plate embedded to avoid impeller jam
Bearing Chinese Best Quality Bearing NSK, SKF, or on request
Mechanical seal Graphene/Ceramic Silicon Carbon
Shaft Carbon Steel Stainless Steel
Insulation Class B Class F
Protection IP44 IP54
Voltage 220-240V Single Phase On Request
Frequency 50HZ 60HZ
thermal protection No Yes
Automatic Pressure Control System No Yes
Cooling Type External Ventilation
Max. Suction lift 9M
Max. Fluid Temperature +60℃
Max. Environment Temperature +40℃
Installation Horizontal
Connect Type Thread
CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC




Peripheral Water Pump TECHNICAL DATA

Model Output A R.P.M. Q.Max H.Max S.Head Pipe Dia LxWxH N.W.
HP / KW 1~220V (l/min) (m) (M) (mm) (Kg)
IDB-35 0.5 / 0.37 1.6 2850 35 35 9 1"x1" 285x150x185 5.4
IDB-40 0.75 / 0.55 3.6 2850 45 50 9 1"x1" 335x180x200 9.6
IDB-50 1 / 0.75 4.8 2850 50 55 9 1"x1" 335x180x200 10.2
IDB-60 1.5 / 1.1 6.2 2850 60 70 9 1½ "x1½" 425x200x225 22



Vortex Agriculture Water Pump 1.5hp / 1.1kw Single Phase With Casting Motor Housing 0




ADVANTAGE

100% a high-quality copper,100% output
Cold-rolled silicon steel sheet by a high-speed punching machine
Good quality bearing, the surface more smooth, the dimension more precise
Thermal protector
One year warranty



Peripheral Water Pump GUARANTEE
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.



FAQ
1. Q: How about the MOQ?
A: Usually, it is 100 PCS for each model.

2.Q: Are you a factory or a trading company?
A: we make water pumps, motors, alternators, and diesel generators since 2006
3. Q: Can you do OEM?
A: Yes, we can. Any OEMs are welcome!
4. Q: What are your payment terms?
A: 30% deposit by T/T in advance, pay 70% balance against B/L copy.
5. Q: How about the delivery time?
A: Usually, 10-30days. But it depends on your order quantity.
6. Q: How about the warranty?
A: 1 year from shipped on board date.
