ZOZHI 2.2kw 3hp Hollow Shaft Electric Motor 100L1-4 Single Phase 380v Waterproof Asynchronous Induction Motor

  • ZOZHI 2.2kw 3hp Hollow Shaft Electric Motor 100L1-4 Single Phase 380v Waterproof Asynchronous Induction Motor
  • ZOZHI 2.2kw 3hp Hollow Shaft Electric Motor 100L1-4 Single Phase 380v Waterproof Asynchronous Induction Motor
Place of Origin CHINA
Brand Name ZOZHI
Certification CE,CCC,ISO9001
Model Number MS160M-6
Minimum Order Quantity 2pieces
Price USD133piece
Packaging Details CTNS/Veneer case
Delivery Time 14work days
Payment Terms T/T,L/C
Supply Ability 10000pieces per30days
Product Details
Asynchronous Speed 1500RPM Insulation Class F
Enclosure IP55 Ambient Temperature 40°C
Frame Size 80-355 Protection Class IP55
Color Customizable Power 3hp/2.2kw
Duty S1(continuous) Torque High
Altitude ≤1000m Rated Frequency 50Hz/60Hz
Mounting Type Foot Mounted
Highlight

2.2kw Electric Motor

,

3hp Induction Motor

,

Hollow Shaft Asynchronous Motor
Leave a Message
Product Description
ZOZHI 2.2kW 3HP Single Phase 380V Electric Motor
High-performance 100L1-4 hollow shaft asynchronous induction motor with waterproof features for industrial applications.
Overall Dimensions
ZOZHI 2.2kw 3hp Hollow Shaft Electric Motor 100L1-4 Single Phase 380v Waterproof Asynchronous Induction Motor 0 ZOZHI 2.2kw 3hp Hollow Shaft Electric Motor 100L1-4 Single Phase 380v Waterproof Asynchronous Induction Motor 1
Frame Dimensions (mm)
Frame Size Flange Frame A AC B H HC L K
90L 75/87 90/61 7 140 238 125 90 220 270 9.5
100L 75/87 90/61 9 160 255 140 100 240 315 11
112M 75/87 90/61 9 216 326 140 132 265 330 11
132S 75/87 90/61 9 216 326 140 132 320 370 12
132M 75/87 90/61 9 216 326 178 132 320 409 12
160M 75/87 90/61 9 254 360 210 160 410 498 14.5
Motor Performance Specifications
Single Phase 50Hz/2-pole Motors
Frame Size Power (HP/kW) Speed (RPM) Power Factor Efficiency (%) Capacitor (μF) Voltage (V) Ampere (A)
HSL90L1-2 2.5HP/1.8kW 2850 0.95 65 50 230 12.7
HSL90L2-2 3HP/2.2kW 2840 0.99 72 60 400 13.4
HSL100L2 3HP/2.2kW 2850 0.96 74 85 400 15.3
Single Phase 50Hz/4-pole Motors
Frame Size Power (HP/kW) Speed (RPM) Power Factor Efficiency (%) Capacitor (μF) Voltage (V) Ampere (A)
HSL90L1-4 2HP/1.5kW 1400 0.98 70 45 230 9.5
HSL100L1-4 2.5HP/1.85kW 1390 0.97 68 55 230 12.2
HSL100L2-4 3HP/2.2kW 1350 0.99 74 70 230 13.1
HSL100L3-4 3.5HP/2.6kW 1350 0.96 74 80 230 17.5
HSL112M1-4 4HP/3kW 1400 0.98 74 80 230 18.1
HSL112M2-4 5HP/3.7kW 1410 0.96 76 100 230 22
Complete three-phase motor specifications available for 2-pole, 4-pole, and 6-pole configurations with power ratings from 1.5HP to 30HP.
