3kW Three-Phase Waterproof High Performance Motor IE2 Efficiency for Hydraulic Pressure Station

Place of Origin	FUAN CHINA
Brand Name	ZOZHI
Certification	CE,ISO
Model Number	MS802-4
Minimum Order Quantity	10pcs
Price	46.5-53.8
Packaging Details	Packed in cartons,veneer case or wooden case.
Delivery Time	25 working days after received your payment
Payment Terms	L/C,T/T
Supply Ability	10000pcs/month

Product Details

Product Name	AC Motor	Application	Drivng
Power	0.75kw	Pole	4
Phase	Three Phase	Housing	Aluminum
Insulation Class	B,F	Protection	IP44 / IP54
Rated Voltage	380V	Duty	S1(continuous)
Highlight	3kW three-phase waterproof motor , IE2 efficiency induction motor , hydraulic pressure station motor

Leave a Message

Product Description

3kW Three-Phase Waterproof High Performance Motor IE2 Efficiency for Hydraulic Pressure Station

MS802-2 0.75kw/400V Electric Motor

This 100% copper wire MS electric motor delivers reliable performance for hydraulic pressure station applications. The motor features IE2 efficiency rating and waterproof construction for demanding industrial environments.

Customization Options

Motors of different voltage, frequency, and power specifications
Motors with various insulation levels and protection ratings
Left appearance, double extension shaft, and unique shaft configurations
High temperature resistant and low-temperature resistant designs
Plateau and outdoor motor variants
Capacity-enhancing motors with different service factors
Motors equipped with heaters, bearing temperature measurement, winding temperature measurement, and thermal protection switches
Motors with photoelectric encoders, insulated bearings, or insulated bearing structures

Technical Specifications

Model	Power HP	Power KW	Voltage (V)	Frequency (HZ)	Current (A)	Power Factor	Efficiency (%)	Speed (r/min)	Tstart/Tn	Tmax/Tn	Ist/In
MS561-2	0.12	0.09	380	50	0.3	0.76	60	2750	2.3	2.4	6
MS562-2	0.16	0.12	380	50	0.37	0.78	63	2750	2.3	2.4	6
MS631-2	0.25	0.18	380	50	0.53	0.75	69	2800	2.2	2.4	4.5
MS632-2	0.33	0.25	380	50	0.68	0.78	72	2800	2.2	2.4	4.5
MS711-2	0.5	0.37	380	50	0.98	0.8	73	2800	2.2	2.4	4.5
MS712-2	0.75	0.55	380	50	1.35	0.82	75	2800	2.2	2.4	4.5
MS801-2	1	0.75	380	50	1.75	0.85	76	2800	2.2	2.4	4.5
MS802-2	1.5	1.1	380	50	2.55	0.85	77	2800	2.2	2.4	4.5
MS90S-2	2	1.5	380	50	3.36	0.87	78	2800	2.2	2.4	4.5
MS90L-2	3	2.2	380	50	4.93	0.87	78	2800	2.2	2.4	5
MS100L-2	4	3	380	50	6.31	0.87	83	2880	2.3	2.4	7
MS112M-2	5.5	4	380	50	8.12	0.88	85	2890	2.3	2.4	7
MS132S1-2	7.5	5.5	380	50	11	0.88	86	2900	2.3	2.4	7
MS132S2-2	10	7.5	380	50	14.9	0.88	87	2900	2.3	2.4	7
MS160L-2	25	18.5	380	50	34.7	0.9	90	2930	2.3	2.4	7
