Low Noise 6p/900rpm 5.5KW IE3 Three Phase Motor

Low Noise 6p/900rpm 5.5KW IE3 Three Phase Motor
Low Noise 6p/900rpm 5.5KW IE3 Three Phase Motor

Large Image :  Low Noise 6p/900rpm 5.5KW IE3 Three Phase Motor

Product Details:

Place of Origin: FUAN CHINA
Brand Name: ZOZHI
Certification: CE,ISO
Model Number: IE3 MS132S-4

Payment & Shipping Terms:

Minimum Order Quantity: 10PCS
Price: $170
Packaging Details: Packed in cartons,veneer case or wooden case.
Delivery Time: 25 working days after received your payment
Payment Terms: L/C, T/T
Supply Ability: 10000pcs/month
Detailed Product Description
Product Name: AC Motor Application: Drivng
Power: 5.5KW/7.5HP Pole: 4
Phase: Three Phase Housing: Aluminum
Insulation Class: B,F Protection: IP44 / IP54
Rated Voltage: 380V Duty: S1(continuous)
High Light:

IE3 Three Phase Motor

,

5.5KW Three Phase Motor

,

6p/900rpm IE3 AC Motor



Descriptions

IE3 series Super high-efficiency three-phase motor are the energy-saving motors. Developed according to the efficiency classification of IEC60034-30. IE2 and IE3 are the worldwide unified efficiency classification of electric motor. USA, Japan,and Europe have stopped the sales of IE2 motors and will replace them with the more efficient IE3 motors even IE4 top high-efficiency motors.

IE3 series Super high-efficiency motor is according to IEC 60034-1 part 1: energy efficiency classification and performance of rotating motor and IEC 60034-2-1 part 2-1: losses and testing method of rotating motor, which is the most authoritative efficiency classification standard in the world. These motors are also in compliance with the efficiency standards covered by USA NEMA, CANADA CSA Premium efficiency,AUSTRALIA AS, NEW ZEALAND NZS, CEMEP, JIS,and Chinese GB motor standard.

IE3 series Super high-efficiency motors are widely used in the power transmission industry fields, such as water pumps, ventilators, machinery tools, HVAC systems,reducers, wood processing machines,mining machines,and construction equipment.

Features:

  • Premium high efficient energy-saving designs
  • High starting torque Low noise
  • Power range:0.75-11kw
  • Frame range:80H-160H
  • Rated Volt:380v,400v,415v,440v,575v,660v,690v.
  • Speed range:2p/3000rpm,4p/1400rpm, 6p/900rpm
  • Construction and Frame housing: TEFC. Cast iron, Aluminum, Steel plate
  • IEC132 Frame and larger frame motors suitable Star/Delta starting
  • Junction box equipped with strong glands
  • Weep holes provide condensation drains
  • Bidirectional fan
  • Motors provided with CE mark
  • Protection class: IP55
  • Thermal protector: Yes
  • Ambient Temperature:-15°C~40°C
  • Altitude: Not exceed 1000m
  • Frequency range:50Hz,60Hz
  • Insulation class: F, H
  • Temperature rise; B
  • Duty; S1,S2.S3
  • Wire connection: Star type for motors up to 3Kw; Delta type for motors 4Kw and above.
  • Bearings: Oversized&sealed ball bearings for DE&NDE(Drive end&Non-drive end)
  • Mount type:
  • B3(feet mount), B5(Big flange mount),C face/B14(small flange mount),
  • V1(end shield with flange).


The difference sample sheet of motors MS, IE2(MS2), IE3(MS3) as below:

Model sample MS motor IE2/MS2 motor IE3/MS3 motor
Efficiency class IE1 IE2 IE3
Efficiency of 4pole-1.1kw 76.2% 81.4% 84.1%
Efficiency of 4pole-5.5kw 85.7% 87% 89.2%
Silicon steel D23,DR510 Hot-rolled DW600/800 Cold-rolled WW470 cold-rolled
Magnet copper wire #120 magnet wire #155 copper rod 180 copper rod
Protection class IP44 IP55 IP55
Government policy Eliminated motors Allow produce and sales Application encouraged



Pre-sales service:
•We is a sales team, with all technical support from the engineering team.
•We value every inquiry sent to us, ensure quick competitive offer within 24 hours.
•We cooperate with customers to design and develop new products. Provide all necessary documents.


After-sales service:
•We respect your feedback after receiving the motors.
•We provide 1-2 years warranty after receipt of motors
•We promises all spare parts available in lifetime use.
•We loge you‘re complaint within 24 hours.





Model Power (V) (A)

Spee

d r/min

Eff.(%) P.F. Tstart/Tn Ist/In Tmax/Tn N.W. (kg)
Kw HP 50% 75% 100%
IE3 MS801-2 0.75 1 230/400 2.82/1.63 2820 79.7 81.0 80.7 0.831 2.3 6.0 2.3 9.5
IE3 MS802-2 1.1 1.5 4.0/2.3 2820 81.5 82.9 82.7 0.836 2.3 7.5 2.3 11
IE3 MS90S-2 1.5 2 5.23/3.02 2840 84.0 85.0 84.2 0.857 2.4 7.5 2.4 15
IE3 MS90L-2 2.2 3 7.44/4.3 2840 86.0 86.5 85.9 0.865 2.4 7.5 2.4 18
IE3 MS100L-2 3 4 9.9/5.72 2850 88.2 87.3 87.1 0.873 2.4 8.0 2.4 25
IE3 MS112M-2 4 5.5 400/690 7.48/4.32 2870 88.0 88.4 88.1 0.880 2.4 8.5 2.4 28.5
IE3 MS132S1-2 5.5 7.5 10/5.8 2900 89.1 89.6 89.2 0.890 2.2 7.5 2.4 41
IE3 MS132S2-2 7.5 10 13.5/7.8 2900 90.0 90.5 90.1 0.892 2.2 7.5 2.4 46.5
IE3 MS160M1-2 11 15 19.5/11.3 2920 89.8 91.3 91.2 0.896 2.2 8.5 2.4 81
IE3 MS160M2-2 15 20 26.2/15.1 2920 91.6 92.0 91.9 0.805 2.2 8.5 2.4 93
IE3 MS160L-2 18.5 25 31.9/18.4 2920 92.1 92.5 92.4 0.910 2.2 8.5 2.4 104
IE3 MS802-4 0.75 1 230/400 2.97/1.72 1400 81.0 82.7 82.5 0.770 2.4 7.0 2.4 12
IE3 MS90S-4 1.1 1.5 4.25/2.45 1420 82.6 84.3 84.1 0.775 2.4 7.5 2.4 16
IE3 MS90L-4 1.5 2 5.68/3.28 1420 83.8 85.4 85.3 0.778 2.4 8.0 2.4 20
IE3 MS100L1-4 2.2 3 8.0/4.62 1440 84.3 86.7 86.7 0.798 2.4 8.0 2.4 26
IE3 MS100L2-4 3 4 10.8/6.2 1440 86.0 87.6 87.7 0.801 2.4 8.0 2.4 30
IE3 MS112M-4 4 5.5 400/690 7.97/4.6 1450 88.3 88.8 88.6 0.821 2.4 7.5 2.4 38
IE3 MS132S-4 5.5 7.5 10.8/6.2 1450 89.0 89.7 89.6 0.825 2.3 7.5 2.4 46
IE3 MS132M-4 7.5 10 14.4/8.32 1450 90.1 90.6 90.4 0.834 2.3 7.5 2.4 54
IE3 MS160M-4 11 15 20.8/12.0 1460 90.5 91.5 91.4 0.838 2.2 7.0 2.4 88
IE3 MS160L-4 15 20 27.9/16.1 1460 91.5 92.5 92.1 0.847 2.2 7.0 2.4 103
IE3 MS90S-6 0.75 1 230/400 3.42/1.97 910 77.5 94.4 78.9 0.700 2 4.0 2.3 15
IE3 MS90L-6 1.1 1.5 4.8/2.78 910 80.2 81.3 81.0 0.710 2 4.0 2.3 20
IE3 MS100L1-6 1.5 2 6.35/3.66 930 81.3 82.6 82.5 0.720 2 5.0 2.3 25
IE3 MS112M-6 2.2 3 8.98/5.2 940 83.2 85.0 84.3 0.730 2 5.0 2.3 30
IE3 MS132S-6 3 4 11.9/6.87 960 84.5 85.8 85.6 0.740 2.2 6.5 2.3 38.5
IE3 MS132M1-6 4 5.5 400/690 9.0/5.2 960 85.3 86.9 86.8 0.745 2.2 7.0 2.3 47.5
IE3 MS132M2-6 5.5 7.5 12.1/7.0 960 86.9 88.2 88.0 0.750 2.2 7.0 2.3 58
IE3 MS160M-6 7.5 10 16.1/9.3 970 87.5 89.0 89.1 0.760 2.2 7.0 2.3 83
IE3 MS160L-6 11 15 22.9/13.2 970 89.0 90.2 90.3 0.770 2.2 7.0 2.3 99
