Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz

China Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz supplier
Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz supplier Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz supplier Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz supplier

Large Image :  Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz

Product Details:

Place of Origin: Fuan, Fujian
Brand Name: ZOZHI
Certification: CE
Model Number: MS562-2

Payment & Shipping Terms:

Minimum Order Quantity: 1CBM
Price: negotiated
Packaging Details: Packed in boxes And Pallet
Delivery Time: 30 days after payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30000 pcs per month
Contact Now
Detailed Product Description
Type: Asynchronous Motor Protect Feature:: Totally Enclosed
Efficiency: IE1 2 3 Protection: IP44/IP54/IP55
Duty: S1 (continuous) Cooling Method:: ICO141
Housing: Aluminium Above Sea Level:: Not Exceed 1000m
Insulation Class:: B/F/H Ambient Temperature:: -15 ℃-40℃
AC Voltage:: 380/660V Frequency:: 50/60Hz

Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz





Three-phase, MS(IE1) series Aluminium housing motors are acknowledged that having good fame for quality and reliability, they are suitable for driving machines which do not have special requirement, such as machine tools, pumps, blowers, etc.

- Superior finish

- Externally Ventilated

- Lightweight construction

- Top-mounted terminal box

- IP55 Protection

- Interchangeable foot mounting and flange mounting



Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz





 Technical Parameters



Model Power (V) (A) P.F. Eff.(%) Speed Tstart/Tn Tmax/Tn
kW HP (r/min)
MS561-2 0.09 0.12 220/380 0.57/0.33 0.68 62 2800 2.3 2.4
MS562-2 0.12 0.16 220/380 0.67/0.38 0.71 67 2800 2.3 2.4
MS631-2 0.18 0.24 220/380 0.91/0.53 0.75 69 2800 2.2 2.4
MS632-2 0.25 0.33 220/380 1.17/0.68 0.78 72 2800 2.2 2.4
MS711-2 0.37 0.5 220/380 1.65/0.95 0.8 73.5 2800 2.2 2.4
MS712-2 0.55 0.75 220/380 2.33/1.35 0.82 75.5 2800 2.2 2.4
MS801-2 0.75 1 220/380 3.03/1.75 0.85 76.5 2800 2.2 2.4
MS802-2 1.1 1.5 220/380 4.42/2.55 0.85 77 2800 2.2 2.4
MS90S-2 1.5 2 220/380 6.01/3.84 0.85 77 2800 2.2 2.4
MS90L-2 2.2 3 220/380 8.61/4.98 0.86 78 2800 2.2 2.4
MS100L-2 3 4 220/380 11.1/6.4 0.87 82 2870 2.2 2.3
MS112M-2 4 5.5 380/660 8.2/4.7 0.87 85.5 2890 2.2 2.3
MS132S1-2 5.5 7.5 380/660 11/6.4 0.88 85.5 2900 2 2.2
MS132S2-2 7.5 10 380/660 15/8.6 0.88 86.2 2900 2 2.2
MS160M1-2 11 15 380/660 21.3/12.2 0.88 88 2930 2 2.2
MS160M2-2 15 20 380/660 28.7/16.4 0.89 89 2930 2 2.2
MS160L-2 18.5 25 380/660 34.6/19.8 0.9 90 2930 2 2.2
MS180M-2 22 30 380/660 40.9/23.4 0.9 90.5 2930 2 2.2

Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz

Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz

Our Customer

Squirrel Cage 3 Phase Electric Motor Aluminum Housing 0.16hp 2800rpm 50/60Hz

Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide the free easy-damaged spare part for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect man-made operation. After expiration, our company provides cost spare parts for maintenance.



Our Service:
1. Free maintenance within 12 months guarantee.
2. We cooperate with customers to design and develop a new product.
3. We'd like to assist you in arranging delivery things, test things or others on your request.
4. Customize production.
1. We are a professional manufacturer with more than 13 years experience in Electric motor
2. We are Made in China Gold Supplier
3.we test the material before production and three to four times when producing to ensure the goods in good quality, also we produce according to request
4.we can be your OEM manufacturer with your authorization of brand.



FAQ:
Q: What’s the MOQ?
A: We accept one piece.

Q: Are you a factory or trading company?
A: We are a manufacturer.

Q: Can you accept to use our logo?
A: Yes, we can do OEM for you.

Q: What’s the warranty period?
A: 1 year.

Q: What are the terms of payment?
A: T/T. 30% deposit and 70% against the BL copy or 100% LC at sight.
