3.7KW 5HP 2000rpm Induction AC Motor 4 Pole YC132S2-4 For Pump Washing Machine

  • 3.7KW 5HP 2000rpm Induction AC Motor 4 Pole YC132S2-4 For Pump Washing Machine
Place of Origin China
Brand Name ZOZHI
Certification ISO
Model Number YC132S2-4
Minimum Order Quantity 1pc
Price negotiated
Packaging Details Packed in cartons,veneer case or wooden case.
Delivery Time 25 working days after received your payment
Payment Terms T/T, L/C
Supply Ability 10000pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Single Phase Induction Motor Application General Driving
Output 3.7KW/5HP Pole 4
Protection Class IP54 Frequency 50Hz
Insulation Class B
Highlight

Pump Washing Machine Induction AC Motor

,

5HP 2000rpm Induction AC Motor

,

3.7KW Asynchronous Induction Motor
Leave a Message
Product Description



3.7KW/5HP 2000rpm Induction AC Motor 4 Pole YC132S2-4 For Pump Washing Machine



Single Phase Induction Motor APPLICATIONS:



YC series capacitor-starting mono phase induction motor.



Product Name 3.7KW/5HP 3000 rpm single phase induction ac motor
Material Copper Winding, Iron Cast or Aluminum Housing.
Color According to your request.
Used Reducer, Air Compressor, Water Pump, Oil Pump, Packing and Food Machinery, etc



YC series motor is designed and manufactured according to national standard JB/T1011. It has the characteristics of simple structure, reliable operation, convenient maintenance, sat is factory technical and economic performance, high starting torque and strong overload, the capacity which is widely used in air compressor, pump washing machine, refrigerator as well as other machines.



MOTOR ADVANTAGE:

1. High efficiency, low noise ac motor
2. 100% copper wire & 100% output.
3. Nice painting after installing the motor
4. Reasonable price with high quality and kind service.
5. Used for machinery without special requirements.
6. Longer working life, easy construction, convenient installation, and repairmen



OPERATING LIMITS:



Ambient temperature:-15℃＜0＜40℃

Ambient temperature: not exceed 1000meters

Rated voltage:220V

Rated frequency:50Hz/60Hz

Duty/Rating:Continuous(running)

Insulation class: Class B/F

Protection class: IP44/54

Cooling method: ICO141



PERFORMANCE CHART:



Type

Out

put

 Voltage
(V)		 Current
(A)		 Freq.
(Hz)		 Power
factor		 Eff(%) Speed

(r/min)		 Tstart/Tn Ist/In Tmax/Tn
kW HP
YC90S-2 1.1 1.5 220 7.2 50 0.95 73.2 2880 2.8 6 1.8
YC90L-2 1.5 2 220 8.9 50 0.97 76 2900 2.8 7 1.8
YC100L-2 2.2 3 220 13.2 50 0.96 78.8 2900 3 6.5 1.8
YC90S-4 0.75 1 220 5 50 0.93 73.3 1450 2.8 6.5 1.8
YC90L-4 1.1 1.5 220 7.8 50 0.9 75 1450 2.5 6 1.8
YC100L-4 1.5 2 220 9.3 50 0.92 79.4 1450 2.8 7 1.8
YC112M-4 2.2 3 220 13.6 50 0.9 81.6 1450 2.3 6.5 1.8
YC132S1-4 3 4 220 18.2 50 0.9 83.2 1450 2.1 6.5 1.8
YC132S2-4 3.7 5 220 22 50 0.9 84.9 1450 2.1 6.5 1.8
YC132M1-4 5.5 7.5 220 32.5 50 0.9 85 1460 2 6.5 1.8
YC132M2-4 7.5 10 220 40 50 0.9 85.5 1460 2 6.5 1.8







3.7KW 5HP 2000rpm Induction AC Motor 4 Pole YC132S2-4 For Pump Washing Machine 0







Single Phase Induction Motor GUARANTEE:



Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.



OUR SERVICE:

1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available. Feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and sample making. Also, we can advise how to make the products according to customers' target prices.


FAQ:


1. Q: What’s the MOQ?
A: We accept one piece.

2. Q: Are you a factory or trading company?
A: We are a manufacturer.

3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.

4. Q: What’s the warranty period?
A: 1 year.



5. Q: What are the terms of payment?

A: T/T. 30% deposit and 70% against the BL copy or 100% LC at sight.
