Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal

Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal
Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal

Large Image :  Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal

Product Details:
Place of Origin: FUAN
Brand Name: ZOZHI
Certification: CE, ISO9001
Model Number: 604
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: negotiated
Packaging Details: Packed in cartons
Delivery Time: 25 working days after received your payment
Supply Ability: 3000000pcs per month
Detailed Product Description
Size:: Standard Size Product Name:: Mechanical Seal
Feature: Rubber Bellows Mechanical Seal Speed:: 50m/sec
Model Number:: 604 Application:: Water Pumps
Pressure:: 2.0Mpa Material Type:: SIC/ INSERTED TC
High Light:

alternator generator parts

,

water pump parts

Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal

Mechanical Seal



Design Features

Internally mounted, single face, metal bellows, balanced, static type seal.



Driven by screws, any rotation direction, compact construction. It can be mounted conveniently



With superior performance of the compensation, material widely used, adaptive capacity, and a high-temperature performance



Materials(to DIN24960)

Rotary Ring: U2 / Q1

Stationary Ring: A / U22/ Q12

Auxiliary Seal: G

Bellows: Y/M/M6

Other Parts: G/G1/T4/M



Operating limits


Pressure: Vacuum~2.0Mpa ( Single-Ply)

                 Vacuum~6.9Mpa (Doubly-Ply)

Temperature:-75~420℃

Speeds:≤ 50m/sec

Viscosity: ≤ 1.0 Pa.s (1000cp) (Solt VS Hard)

                ≤  3.5 Pa.s (1000cp) (Solt VS Hard)



Applications

Used in all types of rotating equipment, pumps. To suit industries such as general chemical, oil refining, petrochemical, pharmaceutical, pulp and paper, and wastewater treatment.


Medium
Hydrocarbon, thermosetting, viscosity high-temperature medium.




Size Information




mechanical seal



 More Products

WATER PUMP SEAL MECHNICAL SEAL Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal 3 MECHNICAL SEAL
MECHNICAL SEAL MECHNICAL SEAL MECHNICAL SEAL BIA MECHNICAL SEAL M7N
Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal 9 M1K Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal 11 Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal 12


easy spare parts

electric motor

water pump
Internally Mounted Seal Water Pump Parts 604 Rubber Bellows Mechanical Seal 16


Mechanical Seal


Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.

Our service:
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and samples making, also we can advise how to make the products according to customers' target prices.


FAQ:
1. Q: What’s the MOQ?
A: We accept one piece.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: What’s the warranty period?
A: 1 year.
5. Q: What are the terms of payment?
A: T/T. 30% deposit and 70% against the BL copy or 100% LC at sight.
