Low Pressure Micro Vortex Pump Single Stage For Garden Sprinkling / Pressure Boosting

Place of Origin Fujian China
Brand Name ZOZHI
Certification CE/SGS/ISO
Model Number QB-60
Minimum Order Quantity 1pc
Price negotiated
Packaging Details Packed in cartons
Delivery Time 25 working days after received your payment
Payment Terms T/T, L/C
Supply Ability 30000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Motor Wire Copper Structure Single Stage Pump
Power 0.75HP / 0.55KW Flow Max 45 L/Min
Head Max 50M Suction Max 9M
Impeller Brass Pressure Low Pressure
Product Name Peripheral Water Pump
High Light

peripheral impeller pump

,

domestic water pump

Leave a Message
Product Description

Low-Pressure Micro Vortex Pump Single Stage For Garden Sprinkling / Pressure Boosting


Peripheral Water Pump


 Features of Domestic Pump

QB micro vortex pump
Pump body: Cast iron
Impeller: Brass
Motor shell: Aluminium
Motor wire: copper
Mechanical seal: Ceramic & Graphite
Shaft: 45# steel
Bearing: China
Insulation class: B
Protection class: IP44

TECHNICAL DATA

ModelOutputAR.P.M.Q.MaxH.MaxS.HeadPipe DiaLxWxHN.W.
HP / KW1~220V(l/min)(m)(M)(mm)(Kg)
QB600.5 / 0.371.62850353591"x1"280x145x1805.3
QB700.75 / 0.553.62850455091"x1"330x180x2209.5
QB801 / 0.754.82850505591½ "x1½"330x180x22010
QB901.5 / 1.16.22850906091½ "x1½"425x200x22022

Other voltages and frequencies available on request
Low Pressure Micro Vortex Pump Single Stage For Garden Sprinkling / Pressure Boosting 0
STRUCTURAL CHARACTERISTICS


Main SpecificationStandardOptional
Transmission mediumClean Water
Pump bodyCast Iron
ImpellerBrass
Motor housingAluminum
Stator&Rotor1. Cold-rolled silicon steel sheet by high-speed punching machine. 2. 100% high-quality copper wire
Front coverCast IronBrass plate embedded to avoid impeller jam
BearingChinese Best Quality BearingNSK, SKF, or on request
Mechanical sealGraphene/CeramicSilicon Carbon
ShaftCarbon SteelStainless Steel
InsulationClass BClass F
ProtectionIP44IP54
Voltage220-240V Single PhaseOn Request
Frequency50HZ60HZ
thermal protectionNoYes
Automatic Pressure Control SystemNoYes
Cooling TypeExternal Ventilation
Max. Suction lift9M
Max. Fluid Temperature+60℃
Max. Environment Temperature+40℃
InstallationHorizontal
Connect TypeThread
CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC


Description

The QB series are peripheral pumps, with peripheral impeller containing numerous radial blades in its edge, suitable for pumping clean water and chemically non-aggressive liquid. They have a relatively simple construction and are very economical, reliable, and safe. It is widely used for household and domestic applications such as water supply from wells and pools, pressure boosting, garden sprinkling, washing booths, etc.
Notice: Pumps should be installed in a covered area, protected against the weather.


Low Pressure Micro Vortex Pump Single Stage For Garden Sprinkling / Pressure Boosting 1



Peripheral Water Pump GUARANTEE
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.

OUR SERVICE

1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available. Feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and sample making. Also, we can advise how to make the products according to customers' target prices.

FAQ
1. Q: What’s the MOQ?
A: Trial sample order is ok.

2. Q: Are you a factory or trading company?
A: We are a manufacturer.

3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.

4. Q: How can I get the pump?
A: Usually, we suggest express for samples. If the volume reaches 1m³, the Seaway will be better.

5. Q: What’s the warranty period?
A: 1 year.
