|Item Name:||Peripheral Water Pump||Head Max:||60 M|
|Flow Max:||90L/min||Pipe Siza:||1½ "x1½"|
|RPM:||2850||Power:||1.1KW / 1.5HP|
peripheral impeller pump,
vortex water pump
High-Pressure Electric Water Pump High Lift For House Water Booster
QB series is constituted with a clean water pump, non-return valve, and air-water separation room, which is located on the upside of the pump body.
During operating, it is no need to use an A foot valve. The only thing that you should do is leave some water in the pump body.
After a few minutes of running, the water will be sucked out, relying on the pump body itself.
They are particularly suitable for domestic applications such as supplying water from well, pools, etc.
It is also suitable for water pressure boosting, gardening, and automatic.
Peripheral Water Pump Description:
Cast iron pump body, stainless steel mechanical seal, brass impeller with radial peripheral blades, #4 steel iron shaft makes this a tough and sturdy water pump
A Single-phase motor is thermally protected against overloads using a thermal device fitted in the winding.
Peripheral Water Pump Technical data:
|HP / KW||1~220V||(l/min)||(m)||(M)||(mm)||(Kg)|
|QB90||1.5 / 1.1||7||2850||90||60||9||1½ "x1½"||425x200x220||22|
Other voltages and frequencies available on request
Produce a line picture:
Peripheral Water Pump Advantages:
2). Highly Efficient
3). Precise centering
4). Easy to operate
5). Flawless design
6). Long service life
7). Robust construction
1). Max Temperature Of Fluid To + 80 ℃
2). Max Pressure 10 Bar
3). Max Ambient Temperature Up To 40 ℃
Peripheral Water Pump guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
1). We are happy that the customer gives us some suggestions for price and products.
2). Any questions, please let us know it in the first by E-mail or Telephone. We can deal with them for you in time.
3). Offer our customers the lowest prices. Streamline the buying and paying processes.
4). Deliver goods to our customers all over the world with speed and precision.
5). Ensure the excellent quality of our products.
6). 12 months FREE warranty.
7). Accept OEM
1). Q: How about the MOQ?
A: Usually, it is 50 PCS for each model.
2). Q: Are you a factory or a trading company?
A: we make water pumps, motors, alternators, and diesel generators since 2006.
3). Q: Can you accept to use our logo?
A: Yes, we can. Any OEMs are welcome!
4). Q: What are your payment terms?
A: 30% deposit by T/T in advance, pay 70% balance against B/L copy.
5). Q: How about the delivery time?
A: Usually, 10-30days. But it depends on your order quantity.
6). Q: How about the warranty?
A: 1 year from shipped on board date.
